Supco Encapsulated Timing Relay,19-250VAC TD73

Single Function Encapsulated Timing Relay, Function – Timing Relay Delay on Break, Input or Control Voltage 19 to 250V AC, Mounting – Relay Surface, Contact Form – Relay SPST-NO, Adjustment Method – Timer Potentiometer, Min. Time Setting – Timer 6 sec, Max. Time Setting – Timer 5 min, Type of Output Solid State

• Supco stock Number TD73.
• Upon application of power, Compressor energizes immediately
• The time delay is initiated when thermostats opens or on power interruption. The compressor contactor will not restart until delay time elapses
• 19 to 250 volts AC 50/60 Hz
