Voltage Signal Generator, 0-10V 0-22mA High Signal Generator, For Voltage Current

Voltage Signal Generator, 0-10V 0-22mA High Signal Generator, for Voltage Current
Specification:
Condition: 100%
Item Type: Voltage Current Signal Generator
Material: ABS
3 Power Supply Methods: Charging with mobile phone charger, power bank or external 24V power supply
External Power Supply: DC15-30V, Power: 1W (Not Charging)/5W (Charging)
Lithium Battery Capacity: 1000mAh, 3.7V
Maximum Charging Current: 0.8A
External: Micro USB- 5V, Current: 0.2A (Not Charging)/1A (Charging)
Voltage Output: 0-10V , Accuracy after Calibration: 0.05V, Maximum Current: 20mA
Current Output: 0-22mA , Accuracy After Calibration: 0.05mA, Current sampling resistance is not more than 500 ohms
Digital Tube Display Digits: 4 digits, two decimal places
Encoder: 20 pulses per turn of the knob
Power Supply: Built-in Lithium battery 1000mAH
Size: Approx. 100x60x25mm / 3.9×2.4×1.0in

Package List:

1 x Signal Generator

1 x USB Cable

4 x Clip

4 x Insulation Clip Cover

1 x Screwdriver

6 x Terminal

1 x Manual

Note:

• Hand held digital signal generator, supports 3 power supply modes, which is more convenient to use.
• Voltage and current adjustments can be switched by one button, adopt independent wiring, and output can be simultaneously performed.
• The output has short circuit protection, and power supply has reverse connection protection, which is safe and reliable.
• With pluggable terminal blocks, it is easy to install, stable in performance and easy to carry around.
