DC 10-55V MAX 60A PWM Motor Speed Controller CW CCW Reversible 12V 24V 36V

Description:
1. Input supply voltage: DC 10V-55V; Maximum current: 60A; Continuous current: 40A; Speed range: 0-100% ; Control frequency: 15KHZ
2.The DC motor speed controller come with switch function. High power speed controller switch which is much more adaptable and conveniently change the motor direction.
3. The enclosure of the speed controller for motor is an aluminum enclosure. Aluminum shell is very strong to prevent damage, holes on its side and top which are helpful for heat dissipation.
4.The stepless motor controller has a simple potentiometer knob adjusts the motor speed from 0% ~ 100% smoothly. And with LED display is accurate to show 0 ~ 100% of the motor speed. The input voltage of pwm motor speed controller should be equal to the rated voltage of the motor within 10-55V,or it will be burnt.
5.The dc motor driver can be used to brush motor speed regulation, light dimming regulation in the DC circuit.Note: The motor cannot be used in electric vehicles

Specification:
Motherboard size: 100*76*28MM
Shell size: 110*78*38MM
Forward & Reverse: Support
Regulation Method: Potentiometer with switch
PWM frequency: 15KHZ
Wiring Type: terminal Knob
Rotary Knob: 100K(with switch)
Suitable for: Brushed DC motor
Bidirectional rotation: setting direction of rotation is optional, which means that accomplishes reversing the motor’s direction

Package:
1 x DC Motor Speed Controller

• Input supply voltage: DC 10V-55V; Maximum current: 60A; Continuous current: 40A; Speed range: 0-100% ; Control frequency: 15KHZ
• The DC motor speed controller come with switch function. High power speed controller switch which is much more adaptable and conveniently change the motor direction.
• The enclosure of the speed controller for motor is an aluminum enclosure. Aluminum shell is very strong to prevent damage, holes on its side and top which are helpful for heat dissipation.
• The stepless motor controller has a simple potentiometer knob adjusts the motor speed from 0% ~ 100% smoothly. And with LED display is accurate to show 0 ~ 100% of the motor speed. The input voltage of pwm motor speed controller should be equal to the rated voltage of the motor within 10-55V,or it will be burnt.
• The dc motor driver can be used to brush motor speed regulation, light dimming regulation in the DC circuit.Note: The motor cannot be used in electric vehicles
