Texas Instruments CD4081BE CD4081 CMOS Quad 2-Input AND Gate (Pack of 5)

Description:

The CD4081BE AND gates, provide the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates.

Included:

• 10 x CD4081BE


This item features:

• Medium-Speed Operation – t_PLH, t_PHL = 60 ns (typ.) at V_DD = 10 V
• 100% tested for quiescent current at 20 V
• Maximum input current of 1 µA at 18 V over full package-temperature range: 100 nA at 18 V and 25°C
• Noise margin (full package-temperature range) =
  • 1 V at V_DD = 5 V
  • 2 V at V_DD = 10 V
  • 2.5 V at V_DD = 15 V
• Standardized, symmetrical output characteristics
• 5-V, 10-V, and 15-V parametric ratings
• Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of ‘B’ Series CMOS Devices"

Condition:

• New and Authentic Component(s) – Texas Instruments CD4081BE CMOS Quad 2-Input AND Gate IC.
